Impact fine crusher sand maker
PXJ-Efficient Impact Fine crusher is used for fine fragmentation of various medium-hardness solid materials. It is widely used in machine-made sand industry (limestone, river gravel, cobblestone, weathered rock, quartz, etc.),
PXJ-Efficient Impact Fine crusher is used for fine fragmentation of various medium-hardness solid materials. It is widely used in machine-made sand industry (limestone, river gravel, cobblestone, weathered rock, quartz, etc.), building materials, cement, refractory and metallurgical and other industries. In the cement industry, It is used to crush limestone, gypsum, clinker, mixed materials, It can also be crushing dolomite, perlite ore and so on.
PXJ-Efficient Impact Fine crusher has this advantage: the output particle size is small, grain-type uniform, large capacity, long-life hammer, and the supporting power is small, Change three-stage crushing into two-stage crushing, process simplification, simple structure, easy maintenance, Stable operation, etc.
型号 Model | 转子规格 Certification（mm） | 进料口尺寸 Feed Opening （mm） | 最大进料 Max.Feed Size （mm） | 出料粒度 Output size （mm） | 出料蓖缝调节宽度 The output adjustment discharge （mm） | 产量Capacity（t/h） | 功率 Power (KW) | ||
水泥熟料 (Clinker) | 石灰石 (limestone) | 玻璃砂 (Glass Sand) | |||||||
PXJ0804 | 800×400 | 400×185 | 120 | ≤5 | 5-20 | 20-30 | 30-45 | 35-45 | 37-45 |
PXJ0806 | 800×600 | 500×250 | 180 | ≤5 | 5-20 | 35-40 | 40-55 | 45-55 | 45-55 |
PXJ0808 | 800×800 | 550×330 | 180 | ≤5 | 5-20 | 35-45 | 60-65 | 55-65 | 45-55 |
PXJ1010 | 1010×1010 | 1000×350 | 180 | ≤5 | 5-20 | 45-55 | 60-75 | 65-75 | 55-75 |
PXJ1210 | 1200×1000 | 1200×400 | 180 | ≤5 | 5-20 | 80-110 | 80-100 | 80-100 | 90-110 |
PXJ1212 | 1200×1200 | 1200×450 | 180 | ≤5 | 5-20 | 100-110 | 90-100 | 90-120 | 110-132 |
PXJ1414 | 1400×1400 | 1500×500 | 190 | ≤5 | 5-20 | 100-150 | 100-150 | 120-150 | 160 |
PXJ1616 | 1600×1600 | 1600×550 | 190 | ≤5 | 5-20 | 170-210 | 190-250 | 190-250 | 250 |
PXJ1818 | 1800×1800 | 1800×800 | 190 | ≤5 | 5-20 | 250-270 | 280-310 | 280-310 | 280-315 |
