Pcx Single-stage Fine Crusher
PCX single-stage fine crusher is a developed new generation of broken equipment on the basis of a high-performance PC hammer crusher and DPC Single-stage hammer Crusher.
PCX single-stage fine crusher is a developed new generation of broken equipment on the basis of a high-performance PC hammer crusher and DPC Single-stage hammer Crusher. It is suitable for crushing limestone, marlite, sandstone, shale,gypsum, coal and other raw materials, with the compressive strength <150MPa .This machine Can crush the big ore from the mine into the size with 5mm, which is the ideal replaced product of traditional two-stage,three-stage crushing method,it can simplify the technological process, save the capital construction investment and production costs.
PCX fine Crusher has the following characteristics:
1, allowing large feeding size (400mm ≤ D ≤ 1200mm)
2, Big crushing ratio,small product size.（D90 ≤ 8mm)
3, The discharging sie can be adjusted within 5-40mm according to requirements.
4, Simple technological process and small land coverage. It save more than 30% energy than the three-stage crushing way.
5, spare parts (hammer, grate plate) durability and long life.Simple structure, Less maintenance
6, a person with a wrench can complete a comprehensive inspection of the machine's maintenance in 20 minutes .
Technical data:
型号 Model | 转子直径 Rotor Diameter(mm) | 进料口尺寸 Inlet Size(mm) | 锤头寿命 Hammer Life(万吨/付)(10000T/pay) | 进料粒度 Feed Size(mm) | 出料粒度 Output Size D平均Average(mm) | 生产能力 Capacity (t/h) | 功率 Power(kw) | 重量 Weight（t) |
PCX-0806Ⅳ | 800 | 630×570 | 1-2 | ≤500 | D平均≤5mm | 10-20 | 30 | 4.5 |
PCX-1090Ⅳ | 1000 | 1050×760 | 3-5 | ≤700 | D平均≤5mm | 30-40 | 55-75 | 10.8 |
PCX-1212Ⅳ | 1200 | 1320×760 | 5-8 | ≤800 | D平均≤5mm | 50-75 | 90-132 | 15.7 |
PCX-1412Ⅳ | 1400 | 1330×960 | 8-12 | ≤900 | D80≤8mm | 80-100 | 132-160 | 21.5 |
PCX-1416Ⅳ | 1400 | 1730×960 | 13-15 | ≤1000 | D80≤8mm | 110-130 | 200-240 | 27.3 |
PCX-1618Ⅳ | 1600 | 2050×1200 | 18-22 | ≤1000 | D80≤10mm | 160-200 | 280-355 | 49.7 |
PCX-1820Ⅳ | 1800 | 2150×1400 | 22-26 | ≤1100 | D80≤10mm | 230-260 | 400-550 | 67.0 |
PCX-2022Ⅳ | 2000 | 2300×1600 | 24-45 | ≤1200 | D80≤10mm | 300-360 | 630-710 | 85.0 |
PCX Single-stage fine crusher instead the old ,tradinational crusher equipment , the equipment is widely used for the stone - made line , or the AAC materials making , It can break the medium hard or high hard limestone,ore , cobblestone,bluestone,gravel and so on , This machine have so many characters , following :
1.allowing large feeding size
2. big break ratio,small production
3.the discharging sie can be adjusted within 10-40 mm , acroding to the customer requiment
4. simple processing technology and small land converage , it can save 30% energy than the three -stage crusher equipment.
5.the crusher equipment is used for the second-break in the stone-making line.
