Mobile Crushing Plant
Mobile crushing plant is mainly used in the raw material processing which always need the moving task, such as in the line of metallurgy, chemistry industries, construction materials, water and electricity. Especially used for fluid stone task in highway, railroad, hydroelectric engineering, which could create more new business opportunities for customers while reducing production cost.
Mobile crushing plant is mainly used in the raw material processing which always need the moving task, such as in the line of metallurgy, chemistry industries, construction materials, water and electricity. Especially used for fluid stone task in highway, railroad, hydroelectric engineering, which could create more new business opportunities for customers while reducing production cost.
参数/型号 Parameter / Model | YM60 | YM75 | YM90 | YM106 | |
产量Output(t/h) | 40-60t/h | 60-100t/h | 80-150t/h | 150-250t/h | |
最大给料粒度Max. Feeding Size(mm) | 340mm | 425mm | 500mm | 630mm | |
粗碎单元 Primary Crushing Unit | 喂料机 Vibrating Feeder | GZD600×1600 | GZD600×1600 | GZD960×3600 | GZD1100×3800 |
颚式破碎机 Jaw Crusher | PE400×600 | PE500×750 | PE600×900 | PE750×1060 | |
输送机 Belt Conveyor | B500 | B500 | B650 | B800 | |
装机功率Moter Power(KW) | 37KW | 62KW | 84.9KW | 104.9KW | |
中细碎及筛分单元 Secondary & Fine Crushing& Screening Unit | 振动筛Vibrating Screen | 3YK1235 | 3YK1545 | 3YK1548 | 3YK1860 |
反击破Impact Crusher | PF1010 | PF1210 | PF1214 | PF1315 | |
装机功率Moter Power(KW) | 60.5KW | 125KW | 178.5KW | 202KW | |
Mobile crushing plant falls into three categories: primary crushing mobile plant, secondary crushing mobile plant and screening mobile plant. Customers could adopt the different allocation format according to the varies and scales of the processing raw materials and the requirement of the finished raw material to fully adapt to various situations of the mobile crushing and screen. And it could also allocate by the customers themselves according to their needs, and also form the different crushing and screen technics flowchart based on the different crushing technics, the crushing and screening can be used separately. The crushing plant could combine the the rough and medium cushing & screening system according to the actual need, and also could combine the primary, secondary and fine crushing & screening system to realize the movement independly, which enjoy the great flexibility.
